Thermo-1200®is a high temperature,water-resistantType I calcium silicate designed to inhibit water absorption. In the event of a typical rainstorm water will bead on the surface of the insulation without penetrating into the substrate. This will allow contractors some additional time to install the insulation without immediately applying the jacketing afterward, offering more time and flexibility in the installation process than has traditionally been available. Additionally, Thermo-1200® contains XOX Corrosion Inhibitor®, a proprietary corrosion inhibiting formula that helps inhibit corrosion under insulation (CUI).
JM Thermo-1200® Quad Pipe Insulation, 38-in IPS, 36 in Length, 2-1/2 in Thickness, Calcium Silicate, Tan, 1200 deg F, BTU Rating: 0.344 to 0.647 Btu-in/hr-sq-ft-deg F, Density: <15 pcf, Compressive Strength: >100 psi, Resists: Abrasion, Fungi and Water
| Additional Information | : | Resists Abrasion, Fungi and Water |
| Application | : | For chemical processing, power generation and petroleum refining applications |
| Color | : | Tan |
| Compressive Strength | : | >100 psi |
| Construction | : | 1-Layer |
| Density | : | <15 pcf |
| Domestic/Import | : | Domestic |
| Facing Type | : | Plain |
| Flame Spread Index | : | 0 |
| Flexural Strength | : | >50 psi |
| For Pipe Size | : | 38 in IPS |
| For Pipe Type | : | Type I |
| Inside Diameter | : | 38 in |
| Iron Pipe Size | : | 38 in |
| Length | : | 3 ft |
| Material | : | Calcium Silicate |
| Smoke Developed Index | : | 0 |
| Style | : | Quad |
| Sub Brand | : | Thermo-1200 |
| Temperature Rating | : | 1200 deg F |
| Thermal Conductivity | : | 0.344 to 0.647 Btu-in/hr-sq-ft-deg F |
| Wall Thickness | : | 2-1/2 in |
- Thermo-1200® is the only North American calcium silicate insulation available that is water-resistant
- The insulation is engineered to withstand a heavy rainfall (1-1/4 in of rain/hr) for up to 20 min without absorbing more than 15% of its weight in water
- This will allow contractors to install the insulation without immediately applying the jacketing afterward, offering more time and flexibility in the installation process than has traditionally been available
- A proprietary corrosion inhibitor, called XOX Corrosion Inhibitor®, is integral to the chemical makeup of Thermo-1200®
- XOX corrosion inhibitor helps protect against corrosion under insulation (CUI) and makes Thermo-1200® one of the least corrosive thermal insulations available
- Thermo-1200® is a cementitious insulation with exceptional compressive strength (>100 psi/690 kPa), making it ideal for applications where mechanical abuse is likely
- The inorganic binder will hold its shape and maintain the physical integrity of the insulation, even past 450 deg F, the point at which most organic binders burn off
- When properly installed and maintained, Thermo-1200® superior physical strength and inorganic binders can provide an insulation lifespan of up to 25 years or more
- Non-combustible, cementitious insulation
- Asbestos, lead and mercury-free
