Types 703 and 705 Series Insulation Boards are made of inorganic glass fibers with a thermosetting resin binder and formed into semi-rigid or rigid rectangular boards. Types 703 and 705 are available with factory-applied FRK or poly encapsulated ASJ Max facings. Both facings are vapor retarders and provide a neat, finished appearance in mechanical applications.
Owens Corning Insulation Board, 700 Series, Type 705 Style, 1-1/2 in Thickness, 24 in Width, 48 in Length, FSK Facing, R-Value: R6.5, Density: 6 pcf, 0.22 to 0.37 Btu-in/hr-sq-ft-deg F Thermal Conductivity, 0 to 450 deg F, Fiberglass, Yellow
| Color | : | Yellow |
| Density | : | 6 pcf |
| Facing Type | : | FSK |
| Length | : | 48 in |
| Material | : | Fiberglass |
| R-Value | : | R6.5 |
| Series | : | 700 Series |
| Style | : | Type 705 |
| Temperature Rating | : | 0 to 450 deg F |
| Thermal Conductivity | : | 0.22 to 0.37 Btu-in/hr-sq-ft-deg F |
| Thickness | : | 1-1/2 in |
| Width | : | 24 in |
- Save and reduce heat transfer, lowering operating costs
- ASJ Max is an all-service-jacket with a polymer film exterior surface that is smooth, durable, cleanable, wrinkle-resistant, resists water staining and doesn't support mold or mildew growth
- The ASJ Max facing can resist short durations of liquid water exposure that can occur during construction
- Resists damage and maintains structural integrity and efficiency
- Efficiently reduces sound transmission
- 703 and 705 are lightweight, resilient, easy-to handle and fabricate on the job site
