Armacell® WST15812 3MNEWST15812
  1. pin-int

armacell® ArmaFlex® WST15812 Tubing Insulation with Reinforced Lap Seal, For Pipe Size: 1-1/2 in, 1/2 in Thick Wall

armacell® ArmaFlex® WST15812 Tubing Insulation with Reinforced Lap Seal, For Pipe Size: 1-1/2 in, 1/2 in Thick Wall
  • Manufacturer: Armacell
  • Brand: Armacell®
  • Item ID: 3MNEWST15812
  • MPN: WST15812
  • LOG IN TO VIEW
  • PRICING & AVAILABILITY

AP ArmaFlex® White LapSeal is specially designed for demanding grocery and refrigeration applications or certain HVAC applications where the highest levels of condensation control, indoor air quality and sanitary appearances are desired. The clean, white surface meets the aesthetic requirements that are common in grocery store ceilings and public-space applications. AP ArmaFlex®, the world’s most recognized brand of closed-cell foam insulation, provides superior protection against thermal losses, condensation and moisture accumulation that leads to mold. It is the ideal choice for insulating mechanical piping systems.

armacell® Tubing Insulation, For Pipe Size: 1-1/2 in, For Pipe Type: Copper, 1-5/8 in, 1.83 in Inside Diameter, 3.02 in Outside Diameter, 1/2 in Thickness Wall, R-Value: R3.2, Thermal Conductivity: 0.245 to 0.254 Btu-in/hr-sq-ft-deg F, -297 to 220 deg F, Elastomeric, White, 6 ft L

Color      :      White
Fiber Free      :      Yes
For Pipe Size      :      1-1/2 in
For Pipe Type      :      Copper
High Temp ��F      :      220 ��F
Inside Diameter      :      1.83 in
Length (Ft)      :      6'
Length      :      6 ft
Low Temp ��F      :      -297 ��F
Material      :      Elastomeric
Nom ID      :      1-5/8"ID
Nom Wall      :      1/2"
Nominal Size      :      1-5/8 in
Outside Diameter      :      3.02 in
R-Value      :      R3.2
Temperature Rating      :      -297 to 220 deg F
Thermal Conductivity      :      0.245 to 0.254 Btu-in/hr-sq-ft-deg F
UV Resistant      :      No
Wall Thickness      :      1/2 in
  • Enhanced seal integrity - reinforced elastic lap seal won’t buckle or lift
  • White color meets aesthetic requirements for many grocery and public-space applications
  • Indoor air quality - low VOC, fiber-free, non-particulating, formaldehyde-free insulation
  • Microban® antimicrobial product protection inhibits the growth of mold and mildew in the insulation
  • Closed-cell foam structure prevents moisture wicking and eliminates need for additional vapor retarder
  • Long-lasting, retains thermal integrity over time
